2.2.5 Applying Newton’s Laws of Motion


Applying Newton’s Laws of Motion

  • Newton's laws of motion are strong tools to understand the motion of objects with forces acting upon them
  • Below are two worked examples demonstrating different situations involving the application of Newton's laws

Worked Example

Two blocks of mass 1 kg and 4 kg respectively are attached by a tight massless rope between them. The 1 kg block sits on the left and the 4 kg block sits on the right. The 1 kg mass has a 100 Newton force applied to it pulling it to the left. What is the acceleration of both blocks and the tension in the rope as they move across a frictionless surface?

A  The acceleration is 15 m s–2 to the left and the tension is 20 N

B  The acceleration is 20 m s–2 to the left and the tension is 40 N

C  The acceleration is 15 m s–2 to the left and the tension is 60 N

D  The acceleration is 20 m s–2 to the left and the tension is 80 N

Step 1: Consider the whole of the system

    • Together the 1 kg and 4 kg blocks are both being pulled along by the 100 N force (since the rope is tight)
    • This is a frictionless flat surface, therefore the only forces in the system are the pulling force and the tension force(s) in the rope
    • Therefore the acceleration can be found using Newton's second law

Boxes System, downloadable IB Physics revision notes

Step 2: Find the acceleration

    • Using Newton's second law:

F = m × a

    • Rearrange for a

a = F ÷ m

a = 100 ÷ 5 = 20 m s–2  to the left

Step 3: Examine the 4 kg mass only

    • Since the system is moving with an acceleration of 20 m s–2  to the left, the force on only the 4 kg mass can be found

F = m × a

F = 4 × 20 = 80 N to the left

    • The only force acting on the 4 kg mass is the rope and therefore tension force
    • This means there is 20 N pulling force on the 1 kg block only

Step 4: State your answer

    • Since acceleration, a = 20 m s–2  to the left and the tension force = 80 N to the left
    • Therefore, the answer is option D

Worked Example

A stationary object is subject to a 300 N force towards the left and at 55 degrees leftwards with respect to the vertical and a 450 N force to the right and 35° downwards with respect to the horizontal.Calculate what is the magnitude and direction of the third force that would make this object remain stationary (to the nearest N).Object Equilibrium, downloadable IB Physics revision notes

Step 1: Recall Newton's first law

    • Newton's First Law states:

A body will remain at rest or move with constant velocity unless acted on by a resultant force

    • Therefore, for this object to remain stationary, the resultant force must have a magnitude of 0 Newtons

Step 2: Resolve the 300 N force into its horizontal and vertical components

    • The horizontal component can be resolved from:

sin(55°) × 300 = 246 N

    • This is directed to the left

    • The vertical component can be resolved from:

cos(55°) × 300 = 172 N

    • This is in an upwards direction

Object Equilibrium-step2, downloadable IB Physics revision notes

Step 3: Resolve the 450 N force into its horizontal and vertical components

    • The horizontal component can be resolved from:

cos(35°) × 450 = 369 N

    • This is directed to the right

    • The vertical component can be resolved from:

sin(35°) × 450 = 258 N

    • This is in a downwards direction

Object Equilibrium-step2, downloadable IB Physics revision notes

Step 4: Combine the horizontal components

    • The two forces provide 369 N to the right and 246 N to the left
    • Therefore, since these are opposing directions:

369 – 246 = 123 N to the right

Step 5: Combine the vertical components

    • The two forces provide 258 N downwards and 172 N upwards
    • Therefore, since these are opposing directions:

258 – 172 = 86 N downwards

Step 6: Make a right angle triangle using these two force vectors

    • There should be a longer size 123 N magnitude vector arrow to the right and then a 86 N magnitude vector arrow downwards
    • These can be connected from start to finish by a third vector which is the hypotenuse of this right-angled triangle

Step 7: Use the two vectors magnitudes to find the angle from the horizon

    • Since the vectors are to the right and downwards in this right-angle triangle, neither is the hypotenuse
    • Therefore the angle from the horizontal downwards can be found by using tan:

tan(θ°) = Opp. ÷ Adj. = 86 ÷ 123

θ° = tan–1(86 ÷ 123) = tan–1(0.699)

θ° ≈ 35°

Step 8: Use Pythagoras theorem or trigonometry to find the magnitude of the resultant force

    • Method 1: Using Pythagoras theorem
      • c2 = b2 + a2 where b and a are the vector magnitudes for the horizontal and vertical components found so far and c is the hypotenuse magnitude

c2 = 862 + 1232 = 7396 + 15129 = 22525

c = √22 525 ≈ 150 N

    • Method 2: Using trigonometry
      • Using the horizontal component and the angle found in step 7, cos can be used

cos(35°) = Adj. ÷ Hyp. = 123 ÷ Hyp.

      • Therefore:

123 ÷ cos(35°) = Hyp. ≈ 150 N

Step 9: State the final answer

    • The third force which would cause this object to remain stationary is 150 N right and 35° downwards from the horizontal

Object-equilibrium-step9, downloadable IB Physics revision notes

Exam Tip

You are expected to know Newton's three laws of motion from memory and how they apply to physical situations. So be sure to practice and use them without having to review them before carrying out a problem.



  • 1. Measurement & Uncertainties
    • 1.1 Measurements in Physics
      • 1.1.1 SI Units
        • 1.1.2 Using Scientific Notation
          • 1.1.3 Estimating Physical Quantities
          • 1.2 Uncertainties & Errors
            • 1.2.1 Random & Systematic Errors
              • 1.2.2 Calculating Uncertainties
                • 1.2.3 Determining Uncertainties from Graphs
                • 1.3 Vectors & Scalars
                  • 1.3.1 Vector & Scalar Quantities
                    • 1.3.2 Combining & Resolving Vectors
                      • 1.3.3 Solving Vector Problems
                    • 2. Mechanics
                      • 2.1 Motion
                        • 2.1.1 Distance & Displacement
                          • 2.1.2 Speed & Velocity
                            • 2.1.3 Acceleration
                              • 2.1.4 Graphs Describing Motion
                                • 2.1.5 Uniform Acceleration
                                  • 2.1.6 Acceleration of Free Fall Experiment
                                    • 2.1.7 Projectile Motion
                                      • 2.1.8 Terminal Speed
                                      • 2.2 Forces
                                        • 2.2.1 Free-Body Diagrams
                                          • 2.2.2 Newton’s First Law
                                            • 2.2.3 Newton’s Second Law
                                              • 2.2.4 Newton’s Third Law
                                                • 2.2.5 Applying Newton’s Laws of Motion
                                                  • 2.2.6 Friction
                                                  • 2.3 Work, Energy & Power
                                                    • 2.3.1 Kinetic Energy
                                                      • 2.3.2 Gravitational Potential Energy
                                                        • 2.3.3 Elastic Potential Energy
                                                          • 2.3.4 Work Done
                                                            • 2.3.5 Power
                                                              • 2.3.6 Principle of Conservation of Energy
                                                                • 2.3.7 Efficiency
                                                                • 2.4 Momentum & Impulse
                                                                  • 2.4.1 Force & Momentum
                                                                    • 2.4.2 Impulse
                                                                      • 2.4.3 Conservation of Linear Momentum
                                                                        • 2.4.4 Collisions & Explosions
                                                                      • 3. Thermal Physics
                                                                        • 3.1 Thermal Concepts
                                                                          • 3.1.1 Solids, Liquids & Gases
                                                                            • 3.1.2 Temperature
                                                                              • 3.1.3 Internal Energy
                                                                                • 3.1.4 Specific Heat Capacity
                                                                                  • 3.1.5 Specific Latent Heat
                                                                                    • 3.1.6 Phase Change
                                                                                      • 3.1.7 Investigating Thermal Energy
                                                                                      • 3.2 Modelling a Gas
                                                                                        • 3.2.1 Ideal Gas Laws
                                                                                          • 3.2.2 Ideal Gas Equation
                                                                                            • 3.2.3 Kinetic Model of an Ideal Gas
                                                                                              • 3.2.4 Mole Calculations
                                                                                                • 3.2.5 Investigating Gas Laws
                                                                                              • 4. Waves
                                                                                                • 4.1 Oscillations
                                                                                                  • 4.1.1 Properties of Oscillations
                                                                                                    • 4.1.2 Simple Harmonic Oscillations
                                                                                                      • 4.1.3 SHM Graphs
                                                                                                        • 4.1.4 Energy in SHM
                                                                                                        • 4.2 Travelling Waves
                                                                                                          • 4.2.1 Properties of Waves
                                                                                                            • 4.2.2 Transverse & Longitudinal Waves
                                                                                                              • 4.2.3 Electromagnetic Waves
                                                                                                                • 4.2.4 Sound Waves
                                                                                                                • 4.3 Wave Characteristics
                                                                                                                  • 4.3.1 Wavefronts
                                                                                                                    • 4.3.2 Amplitude & Intensity
                                                                                                                      • 4.3.3 Superposition
                                                                                                                        • 4.3.4 Polarisation
                                                                                                                          • 4.3.5 Malus’s Law
                                                                                                                          • 4.4 Wave Behaviour
                                                                                                                            • 4.4.1 Reflection, Refraction & Transmission
                                                                                                                              • 4.4.2 Reflection
                                                                                                                                • 4.4.3 Refraction
                                                                                                                                  • 4.4.4 Determining Refractive Index
                                                                                                                                    • 4.4.5 Single-Slit Diffraction
                                                                                                                                      • 4.4.6 Interference & Path Difference
                                                                                                                                        • 4.4.7 Double-Slit Equation
                                                                                                                                        • 4.5 Standing Waves
                                                                                                                                          • 4.5.1 The Nature of Standing Waves
                                                                                                                                            • 4.5.2 Nodes & Antinodes
                                                                                                                                              • 4.5.3 Boundary Conditions for Standing Waves
                                                                                                                                                • 4.5.4 Harmonics
                                                                                                                                              • 5. Electricity & Magnetism
                                                                                                                                                • 5.1 Electric Fields
                                                                                                                                                  • 5.1.1 Charge & Current
                                                                                                                                                    • 5.1.2 Drift Speed
                                                                                                                                                      • 5.1.3 Potential Difference & DC
                                                                                                                                                        • 5.1.4 Electric Fields
                                                                                                                                                          • 5.1.5 Coulomb’s Law
                                                                                                                                                          • 5.2 Heating Effect of Electric Currents
                                                                                                                                                            • 5.2.1 Circuits
                                                                                                                                                              • 5.2.2 Resistance & Resistors
                                                                                                                                                                • 5.2.3 Kirchhoff’s Circuit Laws
                                                                                                                                                                  • 5.2.4 I-V Characteristics
                                                                                                                                                                    • 5.2.5 Resistivity
                                                                                                                                                                      • 5.2.6 Investigating Resistivity
                                                                                                                                                                        • 5.2.7 Series & Parallel Circuits
                                                                                                                                                                          • 5.2.8 Heating Effect of Current
                                                                                                                                                                            • 5.2.9 Potential Divider Circuits
                                                                                                                                                                            • 5.3 Electric Cells
                                                                                                                                                                              • 5.3.1 Primary & Secondary Cells
                                                                                                                                                                                • 5.3.2 Investigating Electric Cells
                                                                                                                                                                                  • 5.3.3 Terminal Potential Difference
                                                                                                                                                                                    • 5.3.4 Electromotive Force & Internal Resistance
                                                                                                                                                                                    • 5.4 Magnetic Effects of Electric Currents
                                                                                                                                                                                      • 5.4.1 Magnetic Fields
                                                                                                                                                                                        • 5.4.2 Magnetic Force on a Charge
                                                                                                                                                                                          • 5.4.3 Magnetic Force on a Current-Carrying Conductor
                                                                                                                                                                                            • 5.4.4 Solving Problems Involving Magnetic Forces
                                                                                                                                                                                          • 6. Circular Motion & Gravitation
                                                                                                                                                                                            • 6.1 Circular Motion
                                                                                                                                                                                              • 6.1.1 Circular Motion
                                                                                                                                                                                                • 6.1.2 Centripetal Force
                                                                                                                                                                                                  • 6.1.3 Centripetal Acceleration
                                                                                                                                                                                                    • 6.1.4 Applications of Circular Motion
                                                                                                                                                                                                    • 6.2 Newton’s Law of Gravitation
                                                                                                                                                                                                      • 6.2.1 Newton’s Law of Gravitation
                                                                                                                                                                                                        • 6.2.2 Circular Orbits
                                                                                                                                                                                                          • 6.2.3 Gravitational Field Strength
                                                                                                                                                                                                        • 7. Atomic, Nuclear & Particle Physics
                                                                                                                                                                                                          • 7.1 Discrete Energy & Radioactivity
                                                                                                                                                                                                            • 7.1.1 Discrete Energy Levels
                                                                                                                                                                                                              • 7.1.2 Calculating Discrete Energies
                                                                                                                                                                                                                • 7.1.3 Emission & Absorption Spectrum
                                                                                                                                                                                                                  • 7.1.4 Isotopes & Radioactive Decay
                                                                                                                                                                                                                    • 7.1.5 Background Radiation
                                                                                                                                                                                                                      • 7.1.6 Alpha, Beta & Gamma Particles
                                                                                                                                                                                                                        • 7.1.7 Decay Equations
                                                                                                                                                                                                                          • 7.1.8 Half-Life
                                                                                                                                                                                                                            • 7.1.9 Investigating Half-Life
                                                                                                                                                                                                                            • 7.2 Nuclear Reactions
                                                                                                                                                                                                                              • 7.2.1 Atomic Mass Unit
                                                                                                                                                                                                                                • 7.2.2 Mass Defect & Nuclear Binding Energy
                                                                                                                                                                                                                                  • 7.2.3 Nuclear Fission & Fusion
                                                                                                                                                                                                                                    • 7.2.4 Binding Energy per Nucleon Curve
                                                                                                                                                                                                                                    • 7.3 The Structure of Matter
                                                                                                                                                                                                                                      • 7.3.1 Discovery of the Nucleus
                                                                                                                                                                                                                                        • 7.3.2 Quarks & Leptons
                                                                                                                                                                                                                                          • 7.3.3 Hadrons, Baryons & Mesons
                                                                                                                                                                                                                                            • 7.3.4 Particle Conservation Laws
                                                                                                                                                                                                                                              • 7.3.5 Fundamental Forces
                                                                                                                                                                                                                                                • 7.3.6 Feynman Diagrams & Confinement
                                                                                                                                                                                                                                                  • 7.3.7 The Standard Model of Particle Physics
                                                                                                                                                                                                                                                • 8. Energy Production
                                                                                                                                                                                                                                                  • 8.1 Energy Sources
                                                                                                                                                                                                                                                    • 8.1.1 Specific Energy
                                                                                                                                                                                                                                                      • 8.1.2 Sankey Diagrams
                                                                                                                                                                                                                                                        • 8.1.3 Primary & Secondary Energy Sources
                                                                                                                                                                                                                                                          • 8.1.4 Energy Resources
                                                                                                                                                                                                                                                            • 8.1.5 Energy Generation
                                                                                                                                                                                                                                                              • 8.1.6 Safety Issues in Nuclear Power
                                                                                                                                                                                                                                                              • 8.2 Thermal Energy Transfer
                                                                                                                                                                                                                                                                • 8.2.1 Conduction, Convection & Thermal Radiation
                                                                                                                                                                                                                                                                  • 8.2.2 Black-Body Radiation
                                                                                                                                                                                                                                                                    • 8.2.3 The Solar Constant, Albedo & Emissivity
                                                                                                                                                                                                                                                                      • 8.2.4 The Greenhouse Effect
                                                                                                                                                                                                                                                                        • 8.2.5 Earth's Surface–Atmosphere System
                                                                                                                                                                                                                                                                      Katie Moon

                                                                                                                                                                                                                                                                      Author: Katie

                                                                                                                                                                                                                                                                      Katie has always been passionate about the sciences, and completed a degree in Astrophysics at Sheffield University. She decided that she wanted to inspire other young people, so moved to Bristol to complete a PGCE in Secondary Science. She particularly loves creating fun and absorbing materials to help students achieve their exam potential.


                                                                                                                                                                                                                                                                      Save My Exams Logo
                                                                                                                                                                                                                                                                      Resources
                                                                                                                                                                                                                                                                      Home Join Support

                                                                                                                                                                                                                                                                      Members
                                                                                                                                                                                                                                                                      Members Home Account Logout

                                                                                                                                                                                                                                                                      Company
                                                                                                                                                                                                                                                                      About Us Contact Us Jobs Terms Privacy Facebook Twitter

                                                                                                                                                                                                                                                                      Quick Links
                                                                                                                                                                                                                                                                      GCSE Revision Notes IGCSE Revision Notes A Level Revision Notes Biology Chemistry Physics Maths 2022 Advance Information


                                                                                                                                                                                                                                                                      © IB Documents (2) Team & u/aimlesskr
                                                                                                                                                                                                                                                                      IBO was not involved in the production of, and does not endorse, the resources created by Save My Exams.
