Home / IB / Economics / SL / Revision Notes / 3. Macroeconomics / 3.2 Variations in Economic Activity (AD & AS) / 3.2.2 Short-Run Aggregate Supply (SRAS)


3.2.2 Short-Run Aggregate Supply (SRAS)


The SRAS Curve

  • Aggregate supply is the total supply of goods/services produced within an economy at a specific price level at a given time
  • The short run is a period in which wages and other factor prices are inflexible
  • The long run is a period in which there is full wage and factor price flexibility

2-3-1-aggregate-supply

A diagram showing the upward sloping short run aggregate supply (SRAS) curve for an economy

  • The AS curve is upward sloping due to two reasons
    • The aggregate supply is the combined supply of all individual supply curves in an economy which are also upward sloping
    • As real output increases, firms have to spend more to increase production e.g. wage bills will increase
      • Increased costs result in higher average prices

A Movement Along the SRAS Curve

  • Whenever there is a change in the average price level (AP) in an economy, there is a movement along the short run aggregate supply (SRAS) curve


77ro3X16_2-3-1-aggregate-supply---movement-along-sras

An increase or decrease in the average price level (AP) causes a movement along the short run aggregate supply (SRAS) curve leading to a contraction or expansion of the quantity supplied



Diagram Analysis

  • An increase in the AP (ceteris paribus) from AP1 → AP2 leads to a movement along the SRAS curve from A → B
    • There is an expansion of real GDP from Y1 → Y2
      • Y is the symbol used in macroeconomics to denote national income or real GDP
  • A decrease in the AP (ceteris paribus) from AP1 → AP3 leads to a movement along the SRAS curve from A → C
    • There is a contraction of real GDP (output) from Y1→Y3

Shifts of the Entire SRAS Curve

  • Whenever there is a change in the non-price determinants of supply in an economy (e.g. costs of production or productivity changes), there is a shift of the entire SRAS curve

2-3-1-aggregate-supply---shift-in-sras

A shift in the entire short run aggregate supply (SRAS) curve occurs due to a change in one of the non-price determinants of supply

Diagram Analysis

  • A decrease in costs or increase in productivity results in a shift right of the entire curve from SRAS1 → SRAS2
    • At every price level, output and real GDP have increased from Y1 → Y2

  • An increase in costs or decrease in productivity results in a shift left of the entire curve from SRAS1 → SRAS3
    • At every price level, output and real GDP have decreased from Y1 → Y3

The Non-price Determinants of the SRAS Curve

  • There are two main factors that can influence the short-run aggregate supply (SRAS). They are
    • Changes in costs of raw materials and energy
    • Changes in indirect taxes

Explaining the Influences on Short-run Aggregate Supply (SRAS)

Change in Condition
Explanation Impact on SRAS

Changes to the costs of raw materials/energy



  • As the price of input costs rise, fewer goods/services can be produced with the same amount of money

SRAS decreases - shifts left

  • As the price of input costs decrease, more goods/services can be produced with the same amount of money

  • Factors which influence the input costs include wage rates, interest rates, government regulation and exchange rates

SRAS increases - shifts right

Changes in indirect taxes




  • Indirect taxes represent an additional cost for firms
  • Decreasing taxes =  decrease in costs
    Lower costs = more output

SRAS increases - shifts right

  • Increasing taxes =  increase in costs
    Higher costs = less output

SRAS decreases - shifts left



  • 1. Introduction To Economics
    • 1.1 What Is Economics?
      • 1.1.1 Economics as a Social Science
        • 1.1.2 The Problem of Choice
          • 1.1.3 The Production Possibilities Curve Model (PPC)
            • 1.1.4 Modelling the Economy
            • 1.2 How Do Economists Approach The World?
              • 1.2.1 Economic Methodology
                • 1.2.2 Economic Thought
              • 2. Microeconomics
                • 2.1 Demand
                  • 2.1.1 Demand, Price & Quantity
                    • 2.1.2 Non-Price Determinants of Demand
                    • 2.2 Supply
                      • 2.2.1 Supply, Price & Quantity
                        • 2.2.2 Non-Price Determinants of Supply
                        • 2.3 Competitive Market Equilibrium
                          • 2.3.1 Market Equilibrium & Disequilibrium
                            • 2.3.2 Functions of the Price Mechanism
                              • 2.3.3 Consumer & Producer Surplus
                              • 2.4 Price Elasticity of Demand (PED)
                                • 2.4.1 Definition, Calculation & Determinants of PED
                                  • 2.4.2 The Significance of PED
                                  • 2.5 Income Elasticity of Demand (YED)
                                    • 2.5.1 Definition, Calculation & Illustration of YED
                                    • 2.6 Price Elasticity of Supply (PES)
                                      • 2.6.1 Definition, Calculation & Determinants of PES
                                      • 2.7 Role of Government In Microeconomics
                                        • 2.7.1 Reasons For Government Intervention In Markets
                                          • 2.7.2 Government Intervention: Indirect Taxes & Subsidies
                                            • 2.7.3 Government Intervention: Price Controls, Direct Provision & Regulation
                                            • 2.8 Market Failure: Externalities & Common Pool (Access) Resources
                                              • 2.8.1 Market Failure
                                                • 2.8.2 Negative Externalities
                                                  • 2.8.3 Positive Externalities
                                                    • 2.8.4 Common Pool (Access) Resources
                                                      • 2.8.5 Government Intervention to Address the Market Failure
                                                        • 2.8.6 Other Interventions to Address the Market Failure
                                                        • 2.9 Market Failure: Public Goods
                                                          • 2.9.1 Public Goods
                                                        • 3. Macroeconomics
                                                          • 3.1 Measuring Economic Activity
                                                            • 3.1.1 National Income & The Circular Flow of Income
                                                              • 3.1.2 National Income Terminology & Calculations
                                                                • 3.1.3 The Business Cycle
                                                                  • 3.1.4 Appropriateness of Using GDP/GNI to Measure Well-being
                                                                    • 3.1.5 Alternative Measures of Well-Being
                                                                    • 3.2 Variations in Economic Activity (AD & AS)
                                                                      • 3.2.1 Aggregate Demand (AD)
                                                                        • 3.2.2 Short-Run Aggregate Supply (SRAS)
                                                                          • 3.2.3 Alternative Views of Aggregate Supply (AS)
                                                                            • 3.2.4 Shifts of the Long-Run Aggregate Supply (LRAS)
                                                                              • 3.2.5 Macroeconomic Equilibrium
                                                                              • 3.3 Macroeconomic Objectives
                                                                                • 3.3.1 An Introduction to Macroeconomic Objectives
                                                                                  • 3.3.2 Economic Growth
                                                                                    • 3.3.3 Low Unemployment
                                                                                      • 3.3.4 Low & Stable Rate of Inflation
                                                                                        • 3.3.5 Potential Conflicts Between Macroeconomic Objectives
                                                                                        • 3.4 Inequality & Poverty
                                                                                          • 3.4.1 Measuring Inequality & Poverty
                                                                                            • 3.4.2 Causes of Inequality & Poverty
                                                                                              • 3.4.3 Using Taxation to Reduce Inequality & Poverty
                                                                                                • 3.4.4 Other Policies to Reduce Inequality & Poverty
                                                                                                • 3.5 Demand Management: Monetary Policy
                                                                                                  • 3.5.1 An Overview of Monetary Policy
                                                                                                  • 3.6 Demand Management: Fiscal Policy
                                                                                                    • 3.6.1 An Overview of Fiscal Policy
                                                                                                    • 3.7 Supply-Side Policies
                                                                                                      • 3.7.1 An Overview of Supply-Side Policies
                                                                                                        • 3.7.2 The Effectiveness of Supply-Side Policies
                                                                                                      • 4. The Global Economy
                                                                                                        • 4.1 Benefits of International Trade
                                                                                                          • 4.1.1 The Advantages of Free Trade
                                                                                                          • 4.2 Types of Trade Protection
                                                                                                            • 4.2.1 Tariffs
                                                                                                              • 4.2.2 Quotas
                                                                                                                • 4.2.3 Export Subsidies
                                                                                                                  • 4.2.4 Administrative Barriers
                                                                                                                  • 4.3 Arguments For & Against Trade Protection
                                                                                                                    • 4.3.1 Arguments For & Against Trade Protection
                                                                                                                    • 4.4 Economic Integration
                                                                                                                      • 4.4.1 Understanding Economic Integration
                                                                                                                        • 4.4.2 Types of Trading Blocs
                                                                                                                          • 4.4.3 The World Trade Organisation (WTO)
                                                                                                                          • 4.5 Exchange Rates
                                                                                                                            • 4.5.1 Types of Exchange Rate Systems
                                                                                                                              • 4.5.2 Causes & Consequences of Exchange Rate Fluctuations
                                                                                                                              • 4.6 Balance of Payments
                                                                                                                                • 4.6.1 Components of the Balance of Payments
                                                                                                                                • 4.7 Sustainable Development
                                                                                                                                  • 4.7.1 The Sustainable Development Goals
                                                                                                                                  • 4.8 Measuring Economic Development
                                                                                                                                    • 4.8.1 Single Indicators of Development
                                                                                                                                      • 4.8.2 Composite Indicators of Development
                                                                                                                                        • 4.8.3 Evaluating the Different Approaches
                                                                                                                                        • 4.9 Barriers to Economic Growth & Development
                                                                                                                                          • 4.9.1 Poverty Traps
                                                                                                                                            • 4.9.2 Economic, Political & Social Barriers
                                                                                                                                            • 4.10 Economic Growth & Development Strategies
                                                                                                                                              • 4.10.1 Trade Strategies, Diversification & Social Enterprise
                                                                                                                                                • 4.10.2 Market-Based & Interventionist Policies
                                                                                                                                                  • 4.10.3 Merit Goods & Inward Foreign Direct Investment
                                                                                                                                                    • 4.10.4 Foreign Aid & Development Assistance
                                                                                                                                                      • 4.10.5 Institutional Change
                                                                                                                                                        • 4.10.6 Evaluating Market Orientated Approaches Versus Government Intervention
                                                                                                                                                          • 4.10.7 Progress Towards Sustainable Development Goals

                                                                                                                                                        Author: Steve



                                                                                                                                                        Save My Exams Logo
                                                                                                                                                        Resources
                                                                                                                                                        Home Join Support

                                                                                                                                                        Members
                                                                                                                                                        Members Home Account Logout

                                                                                                                                                        Company
                                                                                                                                                        About Us Contact Us Jobs Terms Privacy Facebook Twitter

                                                                                                                                                        Quick Links
                                                                                                                                                        GCSE Revision Notes IGCSE Revision Notes A Level Revision Notes Biology Chemistry Physics Maths 2022 Advance Information


                                                                                                                                                        © IB Documents (2) Team & u/aimlesskr
                                                                                                                                                        IBO was not involved in the production of, and does not endorse, the resources created by Save My Exams.
