Home / IB / Economics / SL / Revision Notes / 3. Macroeconomics / 3.2 Variations in Economic Activity (AD & AS) / 3.2.5 Macroeconomic Equilibrium


3.2.5 Macroeconomic Equilibrium


Short-run Equilibrium

  • Real national output equilibrium occurs where aggregate demand (AD) intersects with short-run aggregate supply (SRAS)


2-4-3-short-run-equilibrium

A diagram showing the Classical short-run equilibrium in an economy resulting in an equilibrium price of AP1 and real output of Y1

  • According to classical theory, this economy is in short run equilibrium at AP1Y1
  • Any changes to the components of AD will cause the AD curve to shift left or right creating a new short-run equilibrium
  • Any changes to the non-price determinants of SRAS will shift the SRAS curve left or right creating a new short-run equilibrium

Long-run Equilibrium in the Monetarist/New Classical Model

  • Classical and Keynesian economists have different views on the long-run equilibrium of real national output
  • Classical economists believe that the economy will always return to its full potential level of output and all that will change in the long-run, is the average price level
  • YFE is considered to be equal to the natural rate of unemployment in an economy


2-4-3---long-run-equilibrium---classical

A diagram that shows the Classical view of long-run equilibrium which occurs at the intersection of long-run aggregate supply (LRAS), short-run aggregate supply (SRAS) and aggregate demand (AD)

Diagram Analysis

  • The LRAS curve demonstrates the maximum possible output of an economy using all of its scarce resources
  • The SRAS intersects with AD at the LRAS curve
  • This economy is producing at the full employment level of output (YFE)
  • The average price level at YFE is AP1

The Classical Adjustment Process (Self-correcting)

  • Classical economists believe that in the long run the economy will always return to its full potential level of output and all that will change is the average price level
    • This is the also referred to as the self-correcting mechanism


Automatic adjustment from a deflationary output gap

  • A deflationary (recessionary) output gap occurs when the real GDP is less than the potential real GDP


3-2-5-classical-adjustment-process---from-deflationary-gap

Aggregate demand (AD) has shifted left causing a deflationary gap, which in the long-run will self-correct to YFE but at a lower average price level (AP2)


Correction Process

  1. Initial long-run equilibrium is at AP YFE
  2. AD shifts left from AD → AD1, possibly due to the onset of a recession
  3. Output falls from YFE → Y1 and price levels fall from AP → AP1
  4. Due to the fall in output, firms lay off workers
  5. Unemployed workers are now willing to work for lower wages and this reduces the costs of production which causes the SRAS curve to shift right from SRAS1 → SRAS2
  6. A new long-run equilibrium is formed at AP2 YFE
  7. The economy is back to the full employment level of output (YFE), but at a lower average price


Automatic adjustment from an inflationary output gap

  • An inflationary output gap occurs when real GDP is greater than the potential real GDP


3-2-5--classical-adjustment-process-from-inflationary-gap

Aggregate demand (AD) has shifted right causing an inflationary gap, which in the long-run will self-correct to YFE but at a higher average price level (AP2)


Correction Process

  1. Initial long-run equilibrium is at AP YFE
  2. AD shifts right from AD1 → AD2, possibly due to raid expansion of the money supply
  3. Output rises from YFE → Y1 and price levels rise from AP → AP1
  4. Due to the increase in average prices (inflation), workers demand higher wages
  5. Higher wages increase the costs of production which causes the SRAS curve to shift left from SRAS1 → SRAS2
  6. A new long-run equilibrium is formed at AP2 YFE
  7. The economy is back to the full employment level of output (YFE), but at a higher average price

Equilibrium in the Keynesian Model

  • Keynesian economists believe that the economy can be in long term equilibrium at any level of output

  • The Keynesian view believes that an economy will not always self-correct and return to the full employment level of output (YFE)
    • It can get stuck at an equilibrium well below the full employment level of output e.g. Great Depression

  • The Keynesian view believes that there is role for the government to increase its expenditure so as to shift aggregate demand and change the negative 'animal spirits' in the economy

3-2-5-equilibrium-in-keynesian-modelA diagram that shows the Keynesian View of aggregate supply (AS) with a vertical aggregate supply curve at the full employment level of output (YFE) becoming more elastic at lower levels of output



Diagram Analysis

  • Using all available factors of production, the long-term output of this economy occurs at YFE
  • The economy is initially in equilibrium at the intersection of AD1 and AS (AP1YFE)
  • A slowdown reduces aggregate demand from AD1→AD2 and creates a recessionary gap equal to YFE - Y1
  • The economy may reach a point where average prices stop falling (AP2), but output continues to fall
    • Prices may be blocked from falling further due to minimum wage laws, the existence of trade unions, or long-term employment contracts preventing wage decreases
  • This economy may not self-correct to YFE for years
  • The low output leads to high unemployment and low confidence in the economy
    • This stops further investment and further reduces consumption

  • Keynes argued that this was where governments needed to intervene with significant expenditure e.g. Roosevelt's New Deal; response to financial crisis of 2008

Assumptions & Implications of the two Models

  • Each model has strengths and weaknesses
  • It has been said that free market fans like Classical thinking when an economy is doing well but very quickly switch to a Keynesian way of thought during severe recessions as they seek government bail outs
  • The Economist Mariana Mazzucato sums it up with the phrase, 'Capitalists like to privatise their profits and socialise their losses'


The Assumptions & Implications of Classical Thinking


Assumptions


Implications

Wages are flexible

  • Markets self-correct to YFE in the long run due to the fact that wages can easily rise or fall so as to change costs of production
  • The self-correction is based on automatic short-run supply side changes and there is no need for government intervention

Any deviation from YFE is temporary

  • There may be short periods of unemployment when a recessionary gap occurs, however markets will return to YFE which corresponds to the natural rate of unemployment (NRU) for an economy

Demand-side policies are less effective than supply-side policies in generating economic growth

  • Economic growth is generated by increasing the productive capacity of the economy
  • This thinking follows Says' Law
  • Government intervention should focus on increasing the supply-side of an economy



The Assumptions & Implications of Keynesian Thinking


Assumptions


Implications

'In the long-run we are all dead'

  • Keynes explained that the idea of markets self-correcting in the long-run was flawed in that the long-run could be a very long period of time indeed
  • The consequences of severe recessionary gaps and the unemployment they cause can be significant, lasting for generations

Wages can be inflexible 'sticky' downwards

  • Markets will reach a point where self-correction as a result of falling wages is no longer viable
  • Workers will reach a point where they are no longer willing to accept lower wages
  • Wages may be blocked from falling further due to minimum wage laws, the existence of trade unions, or long-term employment contracts preventing wage decreases

Governments have to intervene to break the 'negative animal spirits'

  • Animal spirits refers to the human emotions which drive financial decisions during times of uncertainty or market volatility
  • If the emotions are gloomy about the economic outlook, then gloominess will continue
  • This was the situation in the Great Depression and Keynes advocated that Government spending was required to change the mood in the economy and to help rebuild business and consumer confidence
  • Once governments had intervened, the self-correcting mechanism would begin to function again


  • 1. Introduction To Economics
    • 1.1 What Is Economics?
      • 1.1.1 Economics as a Social Science
        • 1.1.2 The Problem of Choice
          • 1.1.3 The Production Possibilities Curve Model (PPC)
            • 1.1.4 Modelling the Economy
            • 1.2 How Do Economists Approach The World?
              • 1.2.1 Economic Methodology
                • 1.2.2 Economic Thought
              • 2. Microeconomics
                • 2.1 Demand
                  • 2.1.1 Demand, Price & Quantity
                    • 2.1.2 Non-Price Determinants of Demand
                    • 2.2 Supply
                      • 2.2.1 Supply, Price & Quantity
                        • 2.2.2 Non-Price Determinants of Supply
                        • 2.3 Competitive Market Equilibrium
                          • 2.3.1 Market Equilibrium & Disequilibrium
                            • 2.3.2 Functions of the Price Mechanism
                              • 2.3.3 Consumer & Producer Surplus
                              • 2.4 Price Elasticity of Demand (PED)
                                • 2.4.1 Definition, Calculation & Determinants of PED
                                  • 2.4.2 The Significance of PED
                                  • 2.5 Income Elasticity of Demand (YED)
                                    • 2.5.1 Definition, Calculation & Illustration of YED
                                    • 2.6 Price Elasticity of Supply (PES)
                                      • 2.6.1 Definition, Calculation & Determinants of PES
                                      • 2.7 Role of Government In Microeconomics
                                        • 2.7.1 Reasons For Government Intervention In Markets
                                          • 2.7.2 Government Intervention: Indirect Taxes & Subsidies
                                            • 2.7.3 Government Intervention: Price Controls, Direct Provision & Regulation
                                            • 2.8 Market Failure: Externalities & Common Pool (Access) Resources
                                              • 2.8.1 Market Failure
                                                • 2.8.2 Negative Externalities
                                                  • 2.8.3 Positive Externalities
                                                    • 2.8.4 Common Pool (Access) Resources
                                                      • 2.8.5 Government Intervention to Address the Market Failure
                                                        • 2.8.6 Other Interventions to Address the Market Failure
                                                        • 2.9 Market Failure: Public Goods
                                                          • 2.9.1 Public Goods
                                                        • 3. Macroeconomics
                                                          • 3.1 Measuring Economic Activity
                                                            • 3.1.1 National Income & The Circular Flow of Income
                                                              • 3.1.2 National Income Terminology & Calculations
                                                                • 3.1.3 The Business Cycle
                                                                  • 3.1.4 Appropriateness of Using GDP/GNI to Measure Well-being
                                                                    • 3.1.5 Alternative Measures of Well-Being
                                                                    • 3.2 Variations in Economic Activity (AD & AS)
                                                                      • 3.2.1 Aggregate Demand (AD)
                                                                        • 3.2.2 Short-Run Aggregate Supply (SRAS)
                                                                          • 3.2.3 Alternative Views of Aggregate Supply (AS)
                                                                            • 3.2.4 Shifts of the Long-Run Aggregate Supply (LRAS)
                                                                              • 3.2.5 Macroeconomic Equilibrium
                                                                              • 3.3 Macroeconomic Objectives
                                                                                • 3.3.1 An Introduction to Macroeconomic Objectives
                                                                                  • 3.3.2 Economic Growth
                                                                                    • 3.3.3 Low Unemployment
                                                                                      • 3.3.4 Low & Stable Rate of Inflation
                                                                                        • 3.3.5 Potential Conflicts Between Macroeconomic Objectives
                                                                                        • 3.4 Inequality & Poverty
                                                                                          • 3.4.1 Measuring Inequality & Poverty
                                                                                            • 3.4.2 Causes of Inequality & Poverty
                                                                                              • 3.4.3 Using Taxation to Reduce Inequality & Poverty
                                                                                                • 3.4.4 Other Policies to Reduce Inequality & Poverty
                                                                                                • 3.5 Demand Management: Monetary Policy
                                                                                                  • 3.5.1 An Overview of Monetary Policy
                                                                                                  • 3.6 Demand Management: Fiscal Policy
                                                                                                    • 3.6.1 An Overview of Fiscal Policy
                                                                                                    • 3.7 Supply-Side Policies
                                                                                                      • 3.7.1 An Overview of Supply-Side Policies
                                                                                                        • 3.7.2 The Effectiveness of Supply-Side Policies
                                                                                                      • 4. The Global Economy
                                                                                                        • 4.1 Benefits of International Trade
                                                                                                          • 4.1.1 The Advantages of Free Trade
                                                                                                          • 4.2 Types of Trade Protection
                                                                                                            • 4.2.1 Tariffs
                                                                                                              • 4.2.2 Quotas
                                                                                                                • 4.2.3 Export Subsidies
                                                                                                                  • 4.2.4 Administrative Barriers
                                                                                                                  • 4.3 Arguments For & Against Trade Protection
                                                                                                                    • 4.3.1 Arguments For & Against Trade Protection
                                                                                                                    • 4.4 Economic Integration
                                                                                                                      • 4.4.1 Understanding Economic Integration
                                                                                                                        • 4.4.2 Types of Trading Blocs
                                                                                                                          • 4.4.3 The World Trade Organisation (WTO)
                                                                                                                          • 4.5 Exchange Rates
                                                                                                                            • 4.5.1 Types of Exchange Rate Systems
                                                                                                                              • 4.5.2 Causes & Consequences of Exchange Rate Fluctuations
                                                                                                                              • 4.6 Balance of Payments
                                                                                                                                • 4.6.1 Components of the Balance of Payments
                                                                                                                                • 4.7 Sustainable Development
                                                                                                                                  • 4.7.1 The Sustainable Development Goals
                                                                                                                                  • 4.8 Measuring Economic Development
                                                                                                                                    • 4.8.1 Single Indicators of Development
                                                                                                                                      • 4.8.2 Composite Indicators of Development
                                                                                                                                        • 4.8.3 Evaluating the Different Approaches
                                                                                                                                        • 4.9 Barriers to Economic Growth & Development
                                                                                                                                          • 4.9.1 Poverty Traps
                                                                                                                                            • 4.9.2 Economic, Political & Social Barriers
                                                                                                                                            • 4.10 Economic Growth & Development Strategies
                                                                                                                                              • 4.10.1 Trade Strategies, Diversification & Social Enterprise
                                                                                                                                                • 4.10.2 Market-Based & Interventionist Policies
                                                                                                                                                  • 4.10.3 Merit Goods & Inward Foreign Direct Investment
                                                                                                                                                    • 4.10.4 Foreign Aid & Development Assistance
                                                                                                                                                      • 4.10.5 Institutional Change
                                                                                                                                                        • 4.10.6 Evaluating Market Orientated Approaches Versus Government Intervention
                                                                                                                                                          • 4.10.7 Progress Towards Sustainable Development Goals

                                                                                                                                                        Author: Steve



                                                                                                                                                        Save My Exams Logo
                                                                                                                                                        Resources
                                                                                                                                                        Home Join Support

                                                                                                                                                        Members
                                                                                                                                                        Members Home Account Logout

                                                                                                                                                        Company
                                                                                                                                                        About Us Contact Us Jobs Terms Privacy Facebook Twitter

                                                                                                                                                        Quick Links
                                                                                                                                                        GCSE Revision Notes IGCSE Revision Notes A Level Revision Notes Biology Chemistry Physics Maths 2022 Advance Information


                                                                                                                                                        © IB Documents (2) Team & u/aimlesskr
                                                                                                                                                        IBO was not involved in the production of, and does not endorse, the resources created by Save My Exams.
