11.2.9 Capacitors & Diode Bridges

• In rectification, to produce a steady direct current  or voltage from an alternating current  or voltage, a smoothing capacitor is necessary
• Smoothing is defined as:

The reduction in the variation of the output voltage or current

• This works in the following ways:
  • A single capacitor with capacitance C is connected in parallel with a load resistor of resistance R
  • The capacitor charges up from the input voltage and maintains the voltage at a high level
  • It discharges gradually through the resistor when the rectified voltage drops but the voltage then rises again and the capacitor charges up again

A smoothing capacitor connected in parallel with the load resistor. The capacitor charges as the output voltage increases and discharges as it decreases

• The resulting graph of a smoothed output voltage V_out and output current against time is a ‘ripple’ shape

A smooth, rectified current graph creates a ‘rippling’ shape against time

• The amount of smoothing is controlled by the capacitance C of the capacitor and the resistance R of the load resistor
  • The smaller the rippling effect, the smoother the rectified current and voltage output

• The slower the capacitor discharges, the more the smoothing that occurs ie. smaller ripples
• This can be achieved by using:
  • A capacitor with greater capacitance C
  • A resistor with larger resistance R

• Recall that the product RC is the time constant τ of a resistor
• This means that the time constant of the capacitor must be greater than the time interval between the adjacent peaks of the output signal

Step 1:

Calculate the time constant with the 60 pF capacitor

= 156 ns

Step 2:

Compare time constant of 60 pF capacitor with interval between adjacent peaks of the output signal

• • The time interval between adjacent peaks is 80 ms
  • The time constant of 156 ns is too small and the 60 pF capacitor will discharge far too quickly
  • There would be no smoothing of the output voltages
  • Therefore, the 60 pF capacitor is not suitable

Step 3:

Calculate the time constant with the 800 µF capacitor

= 2.08 s

Step 4:

Compare time constant of 800 pF capacitor with interval between adjacent peaks of the output signal

• • The time constant of 2.08 s is much larger than 80 ms
  • The capacitor will not discharge completely between the positive cycles of the half-wave rectified signal
  • Therefore, the 800 µF capacitor would be suitable for the smoothing task
