5.2.2 Resistance & Resistors

• As electrons move through the metal wire of a circuit (or any other component), they transfer some of their electrical potential energy to the positive ions of the metal

Free electrons collide with metal ions which resist their flow

• This energy results in an increase in the kinetic energy of the lattice
• Which means a higher internal energy of the metal
• The macroscopic result of this transfer is the heating up of the wire
• Some metals heat up more than others
  • The higher the heating, the higher the resistance
  • Wires are often made from copper because copper has a low electrical resistance

• The resistance R of a component is defined as:

The ratio of the potential difference across the component to the current flowing through it

• It is calculated as follows:

• Where:
  • V = potential difference in volts (V)
  • I = electric current in amperes (A)
  • R = resistance in ohms (Ω)

• This means that the higher the resistance of a component, the lower the current flowing through it and vice versa
• In terms of SI base units: 1 Ω = 1 kg m² s^–3 A^–2

Step 1: Write down the known quantities

• • Charge, Δq = 5.0 C
  • Time, Δt = 30 s
  • Potential difference, V = 2.0 V

Step 2: Write down the equation for the resistance R

Step 3: Calculate the current I from the charge and time

Step 4: Substitute the numbers into the above equation

I = 0.17 A

Step 5: Substitute this value of the current into the equation for the resistance given in Step 2

R = 12 Ω

Resistors in Series

• When two or more components are connected in series:

The combined resistance of the components is equal to the sum of individual resistances

• This means as more resistors are added, their combined resistance increases and is, therefore, more than the resistance of the individual components

Connecting more resistors in series increases the overall resistance

Step 1: Write down the known quantities

• • Total resistance, R = 60 Ω
  • Resistance of first resistor, R₁ = 30 Ω
  • Resistance of third resistor, R₃ = 10 Ω

Step 2: Write down the equation for the combined resistance of resistors in series

R = R₁ + R₂ + R₃

Step 3: Rearrange the above equation to calculate the resistance R₂ of the second resistor

R₂ = R – R₁ – R₃

Step 4: Substitute the numbers into the above equation

R₂ = (60 – 30 – 10) Ω

R₂ = 20 Ω

ANSWER: C

Resistors in Parallel

• When two or more components are connected in parallel:

The reciprocal of the combined resistance is the sum of the reciprocals of the individual resistances

• This means as more resistors are added, their combined resistance decreases and is, therefore, less than the resistance of the individual components

Connecting more resistors in parallel decreases the overall resistance

Step 1: Write down the known quantities

• • Resistance of first resistor, R₁ = R
  • Resistance of second resistor, R₂ = 2R
  • Resistance of third resistor, R₃ = R

Step 2: Write down the equation for the reciprocal of the combined resistance (1/R_TOT) of resistors in parallel

Step 3: Substitute the given quantities into the above equation

Step 4: Take the reciprocal of the second equation above to get the combined resistance R_TOT

ANSWER: D
